Description of OEM Customized Size Tungsten Carbide Punching Needle
Our OEM customized size tungsten carbide punching needles are made from virgin WC-Co alloy powder. Based on customer specifications, they are spray-dried to obtain uniform particles with a particle size of 1.0-1.5 μm. These particles are then pressed into blanks using a 200 MPa cold isostatic press to ensure uniform density and zero delamination. After a single sintering process at 1500°C in a vacuum furnace, the blanks achieve a density of 14.8-15.1 g/cm³.
Then, they undergo a high-temperature isostatic pressing (HIP) process at 1350°C and 150 MPa to eliminate internal micropores and reduce porosity to below A02 grade. After forming, the needle body undergoes precision grinding: a centerless diamond grinder maintains an outer diameter tolerance of ±0.005 mm, followed by a five-axis CNC grinder to achieve a tip angle of 0°-90°, an R angle of 0.02-0.5 mm, or a stepped multi-stage structure. The surface is fine-ground with a 1500# diamond grinding wheel to a roughness of Ra ≤ 0.1 μm. If a mirror finish is desired, electrolytic polishing is performed to a roughness of Ra ≤ 0.05 μm. The overall hardness of the needle body is HRA ≥ 91.5, and the flexural strength is ≥ 3000 MPa.
Features of OEM Customized Size Tungsten Carbide Punching Needle
Extremely Tough: The tungsten carbide walls in tools withstand impacts better than diamond. While ordinary steel needles shrink and become blunt after dozens of impacts, the tungsten carbide tip shrinks, flattens, and springs back to its factory dimensions, retaining its original angle.
Resilience Under Pressure: The concrete-lined workshop occasionally experiences impacts, causing steel to collide and collapse, and even nonexistent cushioning to creak. Through these sporadic shocks, tungsten carbide stands firm, maintaining its molecular bonds.
Corrosion Resistance: Tungsten carbide remains stable in a variety of environments, unaffected.
Applications of OEM Customized Size Tungsten Carbide Punching Needle
The application areas of tungsten carbide punching needles are very focused on industrial scenarios that require precision, high efficiency, and large-scale punching. For example, die tools in the pharmaceutical industry, mold needles in the food processing industry, filter screen drilling in the filtration and screening industry, and precision drilling in the electronics industry.
Specifications of OEM Customized Size Tungsten Carbide Punching Needle
|
Material: |
Tungsten carbide |
|
Density: |
14.8~15 g/m³ |
|
Hardness: |
90.5~92 Hra |
|
MOQ: |
No restrictions |
|
Surface： |
Polishing |
|
Size: |
Customized |
|
Origin: |
China |
|
Transport Package: |
Wooden case |
|
OEM： |
Avaliable |
|
Standard： |
ISO, ASTM, AISI |
|
Sample: |
Avaliable |
Testing and quality control of OEM Customized Size Tungsten Carbide Punching Needle
FAQ for OEM Customized Size Tungsten Carbide Punching Needle
Are you an OEM Customized Size Tungsten Carbide Punching Needle factory or an OEM Customized Size Tungsten Carbide Punching Needle manufacturer?
A: Yes, we are an OEM Customized Size Tungsten Carbide Punching Needle factory but we generally use our trading company to handle the business abroad. It will be more convenient to receive the remittance and arrange the shipment.
What is the delivery method of OEM Customized Size Tungsten Carbide Punching Needle?
A: Generally, we send OEM Customized Size Tungsten Carbide Punching Needle by UPS, DHL or FedEx. Also, we can send by sea to a seaport or by air to the closest airport.
Why is your OEM Customized Size Tungsten Carbide Punching Needle so cost-effective?
A: We cut out the middlemen in the end-to-end manufacturing process and we obtain raw material directly from its source.
Do you do spot quality inspection of OEM Customized Size Tungsten Carbide Punching Needle or full inspection of OEM Customized Size Tungsten Carbide Punching Needle?
A: 100% full inspection for sure. All unqualified OEM Customized Size Tungsten Carbide Punching Needles are discarded.
How do you ensure your lead time for OEM Customized Size Tungsten Carbide Punching Needle?
A: From material preparation to machining and finally to a full inspection. Every stage of production is strictly monitored and controlled to give you an accurate delivery time.
What is the MOQ of OEM Customized Size Tungsten Carbide Punching Needle?
A: Depends on the quantity of OEM Customized Size Tungsten Carbide Punching Needle; generally, no MOQ limit.
How to pay for an OEM Customized Size Tungsten Carbide Punching Needle?
A: A bank transfer (T/T) will be acceptable.
What is the delivery time of the OEM Customized Size Tungsten Carbide Punching Needle?
A: Around 7-20 days, which depends on the quantity and production of OEM Customized Size Tungsten Carbide Punching Needle.
What kind of package of OEM Customized Size Tungsten Carbide Punching Needle is it?
A: Generally, we use a carton case or plywood case with protective material inside to ensure the safety of the OEM Customized Size Tungsten Carbide Punching Needle.
What is the lead time of OEM Customized Size Tungsten Carbide Punching Needle?
A: From the order placed to cargo receiving will take around 10-25 days.
