Products Description
Aluminum sputtering targets are of high purity, typically 99.99% or higher. Aluminum has a melting point of 660°C and a thermal conductivity of 235 W/m·K, properties that make it excellent in high-temperature applications. In addition, aluminum forms a corrosion-resistant oxide layer in a vacuum, which enhances its suitability for use in corrosive environments.
Aluminum sputtering targets are used in the semiconductor industry to make conductive layers for chips and circuits. They are also used in car headlights, telescopes, mirror packaging, and toys to enhance the light reflection properties and durability of these products. In the OLED industry, for example, aluminum sputtering targets are widely used for their specific optical properties and thermal control capabilities. In the aerospace field, aluminum targets are used to apply protective coatings that can withstand extreme conditions, helping to improve the safety and efficiency of aircraft.
Features
High purity: usually purity ≥99.9% (3N) to 99.999% (5N), with extremely low impurity content to ensure film performance.
Density: Made by hot pressing or cold pressing sintering process, the density is close to the theoretical value (about 2.7 g/cm³).
Microstructure: fine and uniform grains, reducing particle splashing during sputtering.
Application
Semiconductor industry: metallization layer and electrode (such as Al-Si or Al-Cu alloy target) for integrated circuits.
Display technology: conductive layer or reflective layer in LCD/OLED.
Photovoltaic industry: back electrode or conductive film of solar cells.
Optical coating: preparation of reflectors or decorative coatings.
Packaging materials: barrier film for food/drug packaging (such as Al₂O₃ film).
Common types
Pure aluminum target: purity 99.9%~99.999%, used for general conductive film.
Alloy target: such as Al-Si (silicon content 1%~2%), Al-Cu (copper content 0.5%~2%), improve electromigration performance.
Oxide target: Al₂O₃ is used for insulation or protective layer.
Related Sputtering Materials
AlCu sputtering target
AlSi sputtering target
AlSiCu sputtering target
AlTi sputtering target
AlCr sputtering target
ZnAl sputtering target
Al2O3 sputtering target
AlN sputtering target
FAQ
How to choose the purity of aluminum sputtering target?
99.9%~99.99% (3N-4N): Suitable for general optical coating, packaging materials and other fields with low purity requirements.
≥99.999% (5N): Used in scenes requiring low resistivity and high uniformity such as semiconductors and high-end displays.
Note: The content of impurities (such as Fe, Si) needs to be controlled according to the specific process (for example, semiconductors require Fe<1ppm).
Why do we need alloy aluminum targets (such as Al-Si, Al-Cu)?
Al-Si (1%~2% Si): Prevent "spiking" in semiconductor wiring and improve thermal stability.
Al-Cu (0.5%~2% Cu): Enhance anti-electromigration ability, suitable for high current density devices.
Others: Al-Mg is used to improve corrosion resistance, and Al-Ti is used to increase hardness.
Are you a factory or manufacturer?
A: Yes, we are a factory but we generally use our trading company to handle the business abroad. It will be convenient to receive the remittance and arrange the shipment.
What is the delivery method?
A: Generally, we send cargo by UPS, DHL or FedEx. Also, we can send by sea to seaport or by air to the closest airport.
Why is your product so cost-effective?
A: A: We cut out the middlemen in the end-to-end manufacturing process. We obtain our raw material directly from its source.
Do you do spot quality inspection or full inspection?
A: 100% full inspection. Inspectors will check the finished product individually, to ensure they adhere to all parameters. All unqualified products are discarded.
How do you ensure your lead time?
A: We have an efficient Order Management System, from material preparation to machining, and finally to a full inspection. Every stage of production is strictly monitored and controlled to give you an accurate delivery time.
What is the MOQ of Al target?
A: Depends on quantity, generally, no MOQ limit.
How to pay for it?
A: A bank transfer (T/T) will be acceptable.
What is the delivery time?
A: around 7-20 days which depends on the quantity and production.
What is kind of the package?
A: Generally, we use a carton case or plywood case with protective material inside to ensure the save of cargo
What is the lead time?
A: from order placed to cargo receiving will take around 10-25 days.
