TC4 Titanium Bar For Aviation

TC4 is the most widely used titanium grade, commonly used in the aerospace industry, petrochemical and medical fields. In the aerospace industry in particular, TC4 Titanium Bar For Aviation are often referred to as "space metal" and are used in key forgings that require high strength-to-weight ratios, such as jet engines, pressure vessels, helicopter rotors, compressor blades and discs.

Send Inquiry

Description of TC4 Titanium Bar For Aviation

Titanium has one of the highest strength-to-weight ratios of all metals. TC4 Titanium Bar For Aviation is made of titanium sponge by forging, rolling, vacuum annealing, polishing, and other processing, with low density, light weight, high tensile strength, good dimensional stability, high temperature resistance, oxidation resistance, corrosion resistance, wear resistance, long service life, good biocompatibility, and other titanium alloy advantages.

TC4 is the most widely used titanium grade, commonly used in the aerospace industry, petrochemical, and medical fields. In the aerospace industry in particular, TC4 Titanium Bar For Aviation is often referred to as "space metal" and is used in key forgings that require high strength-to-weight ratios, such as jet engines, pressure vessels, helicopter rotors, compressor blades, and discs.

Manufacturing Process of TC4 Titanium Bar for Aviation

Melting: three vacuum arc melting (VAR) to ensure low impurities.
Thermomechanical processing:
Forging: β phase forging (1050℃±10℃), forging ratio＞6, grain refinement to ASTM 8-10 grade.
Rolling: hot rolling, cold rolling, size range Φ5-200 mm, wall thickness 0.5-25 mm.
Heat treatment: 650℃ vacuum annealing to optimize grain size and residual stress.

Features of TC4 Titanium Bar For Aviation

High strength and light weight

Tensile strength can reach more than 900 MPa, density is only 4.43 g/cm³, specific strength (strength/density) is much higher than steel and aluminum alloy, which can significantly reduce the weight of aircraft structure.

Excellent corrosion resistance

Performs well in humid, salt spray, and acidic environments; no additional anti-corrosion coating is required, suitable for harsh environments (such as marine climates).

Stable high temperature performance

Long-term working temperature can reach 400°C (short-term 500°C), suitable for high-temperature components such as engines.

Good fatigue resistance and fracture toughness

Strong crack propagation resistance, suitable for aviation structural parts subjected to alternating loads.

Specification of TC4 Titanium Bar For Aviation

Grade	Ti-6Al-4VELI, Ti-6Al-7Nb, Ti-N Alloy
Technique	Hot Rolled, Cold Rolled, Cold Drawn, Sintering, Forging, Annealing
Purity	Ti:88-95%
Diameter	Customized
Length	Customized
Tensile Strength	950MPa
Density	4.43g/cm3
Shape	Square, Hexagonal
Surface	Polished, Bright, Ground, Black Oxide, Pickled, etc.
Delivery Time	About 20 days
Standard	ASTM F163

Testing and Quality Control of TC4 Titanium Bar For Aviation

Dimensional accuracy: outer diameter tolerance ±0.127 mm, wall thickness tolerance ±12.5%.
Nondestructive testing: 100% eddy current testing (ET) + ultrasonic testing (UT) to ensure no cracks and inclusions.
