Molybdenum Copper Alloy Bar

Molybdenum copper alloy bar contains 50%-85% Molybdenum. O-Cu copper alloy composites have lower density; their thermal expansion coefficient and thermal conductivity can be adjusted to match many different materials. Molybdenum copper is a great alternative to tungsten copper for weight-sensitive applications. The combination of high-purity raw materials and high-temperature hydrogen sintering using no additives yields the highest thermal conductivity available for this composite material system.

Powder metallurgy method: high-quality molybdenum powder and oxygen-free copper powder are used, and are prepared by isostatic pressing, high-temperature sintering, and copper infiltration. This method ensures product purity and accurate ratio, fine structure, and excellent performance.
Liquid phase sintering method: After the molybdenum-copper mixed powder is pressed into shape, liquid phase sintering is performed at 1300-1500°C. This method is suitable for molybdenum-copper products with low copper content, but there are problems such as poor uniformity and many closed pores.
Skeleton infiltration method: first, press the molybdenum powder into shape and sinter it into a skeleton with a certain porosity, and then infiltrate copper. This method is suitable for molybdenum-copper products with low copper content, but the density of the material after infiltration is low, which may affect air tightness and conductivity.

High Thermal and Electrical Conductivity: Molybdenum-copper rods conduct thermal energy at 200-400 W/m·K and electricity, exhibiting efficient heat and electrical energy transfer.

Low Thermal Expansion: Molybdenum has a low thermal expansion, while copper has a higher one. The ratio of molybdenum to copper can be adjusted; an alloy comprising these two elements can be tailored to meet specific requirements.

High-Temperature Performance: The melting point of molybdenum is 2610°C, which means that this alloy will retain a degree of strength and plasticity at elevated temperatures, even after the copper it contains succumbs to melting.

Non-Magnetic: Molybdenum, along with copper, does not exhibit magnetism, and therefore, the alloy possesses good non-magnetic properties as well.

Good Machinability: The alloy can easily be shaped into more complex forms than pure molybdenum due to its softness and higher ductility.

Corrosion & Oxidation Resistance: The alloy is particularly resistant to oxidation and corrosion and does not corrode even at elevated temperatures.

Aerospace Industry: Molybdenum-copper alloy rods withstand the extremes of heat and mechanical stress, making them suitable for jet engines, rocket nozzles, and combustion chambers.

Electronics: The alloy's application includes serving as IC packaging, a heatsink, or a thermal spreader; thus, preventing government overheating.

High-Temperature Furnace Parts: The rods are used in heating elements and insulation supports for furnaces where high-temperature stability is required.

Medical Equipment: Components requiring extreme reliability and thermal conductivity, made from the alloy, are used in X-ray and other imaging devices.

Vacuum Switches & Electrodes: Due to its wear resistance and excellent conductivity, the alloy is used in electrical contacts and electrodes of vacuum switches.

Surface quality: The surface of the molybdenum-copper alloy rod is turned and must not have defects such as holes, cracks, delamination, or inclusions. Its dimensional accuracy and allowable deviation meet strict standards.
Chemical composition: The ratio of molybdenum and copper, as well as the total amount of impurity elements, is strictly controlled. For example, the copper content of MoCu15 is 15±3%, and the total amount of impurity elements is ≤0.1%.

Are you a factory or a manufacturer?

A: Yes, we are a factory, but we generally use our trading company to handle the business abroad. It will be more convenient to receive the remittance and arrange the shipment.

What is the delivery method?

A: Generally, we send cargo by UPS, DH, L, or FedEx. Also, we can send by sea to a seaport or by air to the closest airport.

Why is your product so cost-effective?

A: We cut out the middlemen in the end-to-end manufacturing process, and we obtain raw material directly from its source.

Do you do spot quality inspection or full inspection?

A: 100% full inspection for sure. All unqualified products are discarded.

How do you ensure your lead time?

A: From material preparation to machining and finally to a full inspection. Every stage of production is strictly monitored and controlled to give you an accurate delivery time.

What is the MOQ of Molybdenum Copper Alloy Bar?

A: Depends on quantity; generally, no MOQ limit.

How to pay for it?

A: A bank transfer (T/T) will be acceptable.

What is the delivery time?

A: around 7-20 days, which depends on the quantity and production.

What kind of package is it?

A: Generally, we use a carton case or a plywood case with protective material inside to ensure the safety of cargo.

What is the lead time?

A: From the order placed to cargo receiving will take around 10-25 days.

What is a molybdenum copper (Mo-Cu) alloy bar?

A Mo-Cu alloy bar is a high-performance material made by combining molybdenum (Mo) and copper (Cu). It offers excellent thermal conductivity, electrical conductivity, and heat resistance while maintaining a low thermal expansion rate.

What are the key properties of Mo-Cu alloy bars?

High thermal & electrical conductivity (200-400 W/m·K)

Adjustable thermal expansion (by changing the Mo/Cu ratio)

High-temperature resistance (Mo's melting point: 2610°C)

Non-magnetic & corrosion-resistant

Good machinability (easier to shape than pure Mo)

Where are Mo-Cu alloy bars commonly used?

Aerospace: Rocket nozzles, jet engine parts

Electronics: Heat sinks, IC packaging

High-temperature furnaces: Heating elements, supports

Medical devices: X-ray & imaging components

Electrical contacts: Vacuum switches, electrodes

Why choose Mo-Cu alloy over pure molybdenum or copper?

Better thermal management than pure copper at high temps

Lower thermal expansion than copper, reducing stress

Easier to machine than pure molybdenum

Balanced strength & conductivity for demanding applications

Can the Mo/Cu ratio be customized?

Yes! The alloy's properties (like expansion rate and conductivity) can be adjusted by changing the molybdenum and copper percentages.

Is Mo-Cu alloy corrosion-resistant?

Yes, it resists oxidation and corrosion well, especially in high-temperature environments.

How does Mo-Cu alloy perform in vacuum conditions?

It works exceptionally well in vacuum applications (e.g., switches, electrodes) due to its stability and low outgassing.

Is this alloy magnetic?

No, both Mo and Cu are non-magnetic, making the alloy suitable for sensitive electronic and medical applications.

Can Mo-Cu alloy be machined into complex shapes?

Yes! It's more ductile than pure molybdenum, allowing precision machining for intricate parts.

Where can I get Molybdenum Copper Alloy Bar?

A: Our company supplies high-quality Molybdenum Copper Alloy Bar along with excellent service. For detailed specifications and pricing, please contact us.
