Monel 400 polished bar
Monel 400 polished bar is a high-performance metal bar made of nickel-copper alloy (Ni-Cu alloy, with a typical composition of 67% nickel, 30% copper, and small amounts of iron, manganese, etc.). It has a smooth and uniform mirror or matte surface after precision machining and surface polishing. Monel 400 polished bar has excellent corrosion resistance, high strength, and good machinability. It is an ideal material for harsh environments.
Monel 400 polished bar is widely used in marine engineering (ship parts, desalination), chemical industry (reactors, corrosion-resistant pipes), oil and gas (downhole tools, equipment in sulfur environments), aerospace (engine parts), and medical and food industries (sanitary parts). Its excellent corrosion resistance, high strength, and polished surface make it a key material in harsh environments.
Features of Monel 400 polished bar
Excellent Corrosion Resistance
Monel 400 polished bar performs well in seawater, acidic media (like sulfuric acid and hydrofluoric acid), alkaline solutions, and high-temperature steam. It has strong resistance to pitting and stress corrosion cracking. It is better than ordinary stainless steel.
High Strength and Toughness
Monel 400 polished bar keeps stable mechanical properties from low temperatures to high temperatures (-200°C to +600°C). Its tensile strength can reach 550-750 MPa. The elongation is over 35%.
Surface Treatment Advantages
The polished surface of Monel 400 polished bar reduces friction and improves anti-adhesion. It is suitable for applications that need cleanliness or good looks.
Easy Machinability
Monel 400 polished bar can be machined by turning, milling, welding and other common processes. No extra coating is needed after polishing.
Applications of Monel 400 polished bar
Marine Engineering: Monel 400 polished bar is used in ship pump shafts, valve components, and desalination equipment to resist seawater corrosion.
Chemical Equipment: Monel 400 polished bar is used to make reactors, heat exchanger pipes and pump and valve parts for transporting corrosive media.
Oil and Gas: Monel 400 polished bar is used to make downhole tools and flange fittings in oil and gas extraction. It can stand sulfur environments.
Aerospace: Monel 400 polished bar is used in engine fasteners and fuel system components. It can deal with both high stress and corrosion.
Medical and Food Industry: The polished surface of Monel 400 polished bar meets health standards. It is used in corrosion-resistant parts of medical implants or food processing equipment.
|
Parameter |
Specification Range/Value |
Remarks |
|
Diameter (mm) |
5 - 200 |
Custom sizes available |
|
Length (mm) |
1000 - 6000 (standard) |
Custom cut lengths possible |
|
Tolerance Grade |
h9 / h10 (precision) |
Complies with ASTM B164 |
|
Surface Finish |
Ra ≤ 0.8μm (mirror polish) |
Matte or bright finish options |
|
Tensile Strength |
550 - 750 MPa |
Typical (per ASTM) |
|
Yield Strength |
≥ 240 MPa |
Varies with heat treatment |
|
Elongation |
≥ 35% |
50mm gauge length |
|
Hardness |
150 - 200 HB |
Cold-worked versions available (higher hardness) |
|
Density |
8.80 g/cm³ |
Nickel-copper alloy property |
|
Standards |
ASTM B164, ASME SB164, DIN 17752 |
Material certifications (MTC) provided |
FAQ
Are you a factory or manufacturer?
A: Yes, we are a factory but we generally use our trading company to handle the business abroad. It will be more convenient to receive the remittance and arrange the shipment.
What is the delivery method?
A: Generally, we send cargo by UPS, DHL or FedEx. Also, we can send by sea to seaport or by air to the closest airport.
Why is your product so cost-effective?
A: We cut out the middlemen in the end-to-end manufacturing process and we obtain raw material directly from its source.
Do you do spot quality inspection or full inspection?
A: 100% full inspection for sure. All unqualified products are discarded.
How do you ensure your lead time?
A: From material preparation to machining and finally to a full inspection. Every stage of production is strictly monitored and controlled to give you an accurate delivery time.
What is the MOQ of Monel 400 polished bar?
A: Depends on quantity, generally, no MOQ limit.
How to pay for it?
A: A bank transfer (T/T) will be acceptable.
What is the delivery time?
A: around 7-20 days which depends on the quantity and production.
What is kind of the package?
A: Generally, we use a carton case or plywood case with protective material inside to ensure the save of cargo
What is the lead time?
A: from order placed to cargo receiving will take around 10-25 days.
