Inconel 713C K418 thin wall thickness tube
Inconel 713C K418 thin wall thickness tube is made by precision casting or cold and hot working. The wall thickness is usually between 0.5 mm and 3 mm. It has excellent geometric accuracy and surface finish. Inconel 713C K418 thin wall thickness tube is based on nickel and chromium. It adds aluminum and titanium to form gamma prime (γ') strengthening phase. It also uses molybdenum, niobium and other elements to improve overall performance. It is used for structural parts in extreme working conditions.
Inconel 713C K418 thin wall thickness tube is widely used in aerospace (such as turbine engine combustion chamber parts), energy fields (gas turbine cooling tubes, nuclear reactor heat exchangers), and high - end industries (chemical sensor sheaths, semiconductor heat - resistant chambers). Inconel 713C K418 thin wall thickness tube has high - temperature strength, corrosion resistance and lightweight characteristics. It is a key material in extreme environments. But it is expensive. It is mostly used in high - value - added fields.
Features of Inconel 713C K418 thin wall thickness tube
Excellent high - temperature performance: Inconel 713C K418 thin wall thickness tube can work for a long time at 800 - 950℃. It has excellent oxidation resistance and creep resistance. Its high - temperature strength is much better than that of ordinary stainless steel.
Lightweight and high strength: The thin - walled design of Inconel 713C K418 thin wall thickness tube reduces weight. At the same time, it keeps high specific strength through gamma prime (γ') phase strengthening. It is suitable for applications that are sensitive to weight.
Strong corrosion resistance: Inconel 713C K418 thin wall thickness tube has excellent resistance to gas sulfides, salt spray and hot corrosion. It is suitable for marine or chemical corrosive environments.
High - tech manufacturing challenges: Because the alloy has low thermal conductivity and a strong tendency for work hardening, special processes such as laser welding or superplastic forming are needed to form thin - walled tubes.
Applications of Inconel 713C K418 thin wall thickness tube
Aerospace: Inconel 713C K418 thin wall thickness tube is used in turbine engine combustion chamber liners and transition ducts. It meets the requirements of weight reduction and heat resistance.
Energy sector: Inconel 713C K418 thin wall thickness tube is used as gas turbine blade cooling channel tubes or nuclear reactor heat exchanger components. It can endure high - pressure thermal cycling.
High - end industry: Inconel 713C K418 thin wall thickness tube is used in high - temperature sensor sheaths in chemical equipment and heat - resistant chambers in semiconductor manufacturing equipment. It ensures long - term stability.
|
Parameter |
Specification Range |
Remarks |
|
Outer Diameter (OD) |
5 mm – 150 mm |
Custom sizes available |
|
Wall Thickness |
0.5 mm – 3 mm |
Ultra-thin walls require special processing |
|
Length |
500 mm – 6000 mm |
Custom cut lengths available |
|
Tolerance |
±0.05 mm (precision grade) |
Tighter tolerances for critical applications |
|
Material Standard |
AMS 5392 (U.S. Standard) |
Equivalent to Chinese grade K418 |
|
Manufacturing Process |
Precision casting / Cold rolling + welding |
Depends on thickness & performance requirements |
|
Operating Temperature |
-200°C to 950°C |
Long-term service limit ~950°C |
|
Surface Finish |
Pickling / Polishing / Coating |
Customized for corrosion resistance or assembly needs |
FAQ
Are you a factory or manufacturer?
A: Yes, we are a factory but we generally use our trading company to handle the business abroad. It will be more convenient to receive the remittance and arrange the shipment.
What is the delivery method?
A: Generally, we send cargo by UPS, DHL or FedEx. Also, we can send by sea to seaport or by air to the closest airport.
Why is your product so cost-effective?
A: We cut out the middlemen in the end-to-end manufacturing process and we obtain raw material directly from its source.
Do you do spot quality inspection or full inspection?
A: 100% full inspection for sure. All unqualified products are discarded.
How do you ensure your lead time?
A: From material preparation to machining and finally to a full inspection. Every stage of production is strictly monitored and controlled to give you an accurate delivery time.
What is the MOQ of Inconel 713C K418 thin wall thickness tube ?
A: Depends on quantity, generally, no MOQ limit.
How to pay for it?
A: A bank transfer (T/T) will be acceptable.
What is the delivery time?
A: around 7-20 days which depends on the quantity and production.
What is kind of the package?
A: Generally, we use a carton case or plywood case with protective material inside to ensure the save of cargo
What is the lead time?
A: from order placed to cargo receiving will take around 10-25 days.
