Incoloy 800HT straight weld wires
Incoloy 800HT straight weld wires are a kind of nickel-iron-chromium alloy welding materials. They are designed for high-temperature and corrosion-resistant environments. They meet the standards of ASTM B408, B409 and so on. The composition of Incoloy 800HT straight weld wires is Ni-30% to 35%, Cr-19% to 23%, and Fe is the balance. Titanium (Ti) and aluminum (Al) are added to stabilize it. The carbon content is strictly controlled at 0.06% to 0.10%. This optimizes the high-temperature strength and anti-creep properties. Incoloy 800HT straight weld wires are suitable for TIG (tungsten inert gas welding) and MIG (metal inert gas welding). They are often used to weld high-temperature parts of the same material or different metals.
Incoloy 800HT straight weld wires are widely used in high-temperature and high-pressure parts such as petrochemical cracking furnace tubes, gas turbine combustion chambers, and nuclear power heat exchangers. They are also used in corrosion-resistant scenes such as heat treatment furnace rollers and waste gas treatment systems. They ensure the anti-oxidation, anti-creep and sulfur/chlorine corrosion resistance of the welded joints at 600°C to 900°C. This greatly improves the life and safety of the equipment.
Features of Incoloy 800HT straight weld wires
Excellent high-temperature performance
Incoloy 800HT straight weld wires have excellent oxidation resistance, carburization resistance and sulfurization resistance in the range of 600°C to 900°C. They still keep stable mechanical properties after long-term service.
They have high creep-rupture strength. They are suitable for high-pressure and high-temperature environments like petrochemical cracking furnaces and heat treatment equipment.
Corrosion resistance
Incoloy 800HT straight weld wires resist corrosion from acid and alkali media. They perform better than common stainless steel (such as 304/316) in environments with sulfur and chloride ions.
Process adaptability
The welding pool of Incoloy 800HT straight weld wires flows well. There is little spatter. The weld bead forms evenly. This can reduce the need for post-weld heat treatment.
They match well with Incoloy 800HT base metal. This avoids the risk of hot cracking and intergranular corrosion.
Applications of Incoloy 800HT straight weld wires
Petrochemical industry: Incoloy 800HT straight weld wires are used for welding cracking furnace tubes, reformer parts and high-temperature pipes.
Energy and power: Incoloy 800HT straight weld wires are used for welding gas turbine combustion chambers, boiler superheaters and nuclear power heat exchangers.
Industrial heating: Incoloy 800HT straight weld wires are used for welding heat treatment furnace rollers, radiant tubes and sintering equipment.
Environmental engineering: Incoloy 800HT straight weld wires are used for welding the high-temperature parts of waste gas treatment systems (such as SCR reactors).
|
Parameter |
Specification/Value |
Remarks |
|
Material Standard |
AWS A5.14 ERNiCr-3, ASTM B408/B409 |
Complies with international standards |
|
Diameter (mm) |
0.8, 1.0, 1.2, 1.6, 2.0, 2.4, 3.2 |
Common sizes, customizable |
|
Packaging Form |
Straight Length |
Standard lengths: 1m / 3m |
|
Chemical Composition (%) |
Ni: 30-35, Cr: 19-23, Fe: Balance |
Ti & Al stabilized, C: 0.06-0.10 |
|
Tensile Strength (MPa) |
≥550 |
Typical welded joint value |
|
Elongation (%) |
≥30 |
Indicates good ductility |
|
Applicable Processes |
TIG (GTAW), MIG (GMAW), SAW |
Shielding gas: Ar or Ar+He mix |
|
Operating Temperature |
600°C ~ 900°C |
Long-term high-temperature stability |
FAQ
Are you a factory or manufacturer?
A: Yes, we are a factory but we generally use our trading company to handle the business abroad. It will be more convenient to receive the remittance and arrange the shipment.
What is the delivery method?
A: Generally, we send cargo by UPS, DHL or FedEx. Also, we can send by sea to seaport or by air to the closest airport.
Why is your product so cost-effective?
A: We cut out the middlemen in the end-to-end manufacturing process and we obtain raw material directly from its source.
Do you do spot quality inspection or full inspection?
A: 100% full inspection for sure. All unqualified products are discarded.
How do you ensure your lead time?
A: From material preparation to machining and finally to a full inspection. Every stage of production is strictly monitored and controlled to give you an accurate delivery time.
What is the MOQ of Incoloy 800HT straight weld wires ?
A: Depends on quantity, generally, no MOQ limit.
How to pay for it?
A: A bank transfer (T/T) will be acceptable.
What is the delivery time?
A: around 7-20 days which depends on the quantity and production.
What is kind of the package?
A: Generally, we use a carton case or plywood case with protective material inside to ensure the save of cargo
What is the lead time?
A: from order placed to cargo receiving will take around 10-25 days.
